XCMG QAY 600

We have all the parts for the machinery:ROCK BUCKET/SKELETON BUCKET /LOOSENING BUCKET/CLEANING BUCKET TILT BUCKET/DITCH BUCKET/BUCKET CLAMP/CLAMSHELL BUCKET/ROTARY SCREEN/CRUSHER BUCKET/RUSHER BUCKET CRUSHING AND SCREENING BUCKET/RAKE/RIPPER/THUMB CLIP/COMPACTION WHEEL Business hours:24 hours, holidays and Sundays Contact: Lily Whatsapp: +86 17756597429 Mobile:+86 17756597429 Wechat:17756597429 Packaging Details 1. Flat frame is more suitable for large construction equipment without disassembly. 2. Containers are the cheapest and fastest. 3. Bulk carriers are more suitable for large construction equipment. 4. Ro-ro shipment is fast and suitable for all kinds of machines. You can choose any mode of transportation according to your needs.

The main parameters of XCMG QAY600 all-terrain crane are as follows: Basic parameters The dimensions of the whole machine: length × width × height is about 15.68×3.00×4.05 meters. Driving state dead weight (gross mass): approx. 80 tons. Maximum rated gross lifting capacity: 600 tons. Power parameters Engine model: Weichai WP12.460E50 engine is adopted. Engine rated power: 338kW/1900r/min. Engine rated torque: 2200N·m/1100-1400r/min. Driving parameters Maximum driving speed: ≥75km/h. Minimum turning diameter: ≤24m. Minimum ground clearance: 295mm. Approach angle: 18°. Departure angle: 15°. Maximum climbing capacity: ≥45%. Main performance parameters Minimum rated amplitude: 3m. Rotary radius of the tail of the turntable: 4.5m. Maximum lifting torque: 20,000kN·m. Basic arm length: 15m. Longest main arm: 84m. Longest main arm Knee arm: 120m. Longitudinal distance of outriggers: 7.6m. Outrigger lateral distance: 8m. Working speed parameters Luffing time of lifting arm: 60s. Crane boom full extension and full contraction time: ≤150s. Maximum rotation speed: 1.5r/min. Maximum speed of the main lifting mechanism (single rope): 120m/min. Maximum speed of sub-lifting mechanism (single rope): 100m/min.
