Hamm HD 10 VV

Hamm HD 10 VV Mini Road Roller Specifications Type: Double-drum vibratory tandem roller from the HD CompactLine series Operating weight (with ROPS): ~2,475 kg; Maximum operating weight: ~3,190 kg Drum width (front / rear): 1,000 mm each Maximum working width: 1,050 mm Dimensions (L × W × H): Length: ~2,530 mm Width: ~1,110 mm Height with ROPS: ~2,475 mm Drum diameter / shell thickness: Ø 720 mm / 15 mm (front and rear) Static linear loads: Front: ~12.1 kg/cm Rear: ~12.7 kg/cm Travel speed: infinitely variable, up to ≈10.2 km/h Gradeability: 30% with vibration, 40% without Steering: Articulated steering with ±8° swing angle Engine Manufacturer: Kubota Model: D1703-M-DI-E4B Power: 18.2 kW (24.8 hp) @ 2,200 rpm Emission standard: EU Stage V / EPA Tier 4 Vibration system: Frequency (front & rear): 65 Hz (I) / 51 Hz (II) Amplitude: 0.45 mm (both frequencies) Centrifugal force: 33 kN (I) / 20 kN (II) (front & rear) Tank capacity: Fuel: 42 L Water: 180 L (pressure sprinkling system)
