Shantui SL50W

ITEM SL50W Engine Weichai WD10G220E23 Rated power (kW/rpm) 55/679 Displacement (L) 9.726 Minimum diesel consumption (g/kW•h) 215 Ma×imum torque (NM) 900 Operating weight (kg) 17000 Dimension L×W×H (mm) 8054×3072×3410 Center distance of tires (mm) 2250 Wheel base (mm) 3250 Loading capacity (t) 5 Bucket capacity (m3) 3 Ma×imum traction force (KN) 162 Ma×imum breakout force (KN) 185 Static tipping load (full turn) (kg) 10000 Gradeability (°) 30 Minimum turning radius (mm) Outside of bucket 6590 Outside of tire 7256 Turning angle (°) 36 Dumping height (mm) Standard Arm 3178 E×tended 3350 Long 3676 Dumping reach (mm) Standard Arm 1160 E×tended 1110 Long 954 Lifting/Lifting,dumping and lowering time (S) 54/109 Travel speed (km/h) Forward 1 0–13 or 0–8 Forward 2 0–38 or 0–15 Forward 3 (n/a)or 0–24 Forward 4 (n/a) or 0–38 Reverse 1 0–17 or 0–8 Reverse 2 (n/a) or 0–24 Reverse 3 -
